Description
This Is What a Heavy-Duty Performance Wheelchair Looks Like
It’s time to put limited mobility where it belongs — on the sidelines.
When adventure calls at a moment’s notice, Jazzy EVO 614HD empowers you to pick up and go. That’s because it comes engineered with the capabilities that push boundaries of everyday life for the heavy-duty power wheelchair class, with a 450-pound weight capacity.
Here’s how the Jazzy EVO 614HD pushes the limits.
We introduced a new 4.88 mph top speed. Compared to the average person’s walking speed of around 2 mph, that’s cheetah-fast.
With a new 3” ground clearance and new 13.75” drive wheels, you sit higher and blaze over uneven terrain like you were born to do it.
Specifications:
Model |
Jazzy® EVO 614HD
|
Weight Capacity |
450 lbs. |
Turning Radius3 |
22″ |
Width3 |
25.75″ |
Length3 |
40.5″ |
Maximum Speed2 |
Up to 4.88 mph |
Ground Clearance3 |
3″ |
Front Wheels |
6″ casters |
Drive Wheels |
13.75″ solid |
Rear Wheels |
6″ casters |
Drivetrain |
Two motor, in-line, HD motors |
Braking System |
Regenerative and electro-mechanical |
Suspension Type |
Full independent front and rear Active-Trac® (ATX) Suspension |
Standard Seat Sizes |
High-back, memory foam
Black vinyl
18″x18″-20″, 20″x18″-20″, 22″x20-“-22” |
Seat-to-Floor Range |
22″-24″ |
Seat Weight(s)3 |
57.8 lbs |
Maximum Seat Size |
22″W-22″D |
Power Elevating Seat |
NA |
Standard Electronics |
60A, Dynamic Linx |
Battery Size(s)4 |
(2) NF-22 |
Battery Weight6 |
36-lbs. each |
Battery Charger |
5-amp, off-board |
Per Charge Range2,3,5 |
13 miles at 450 lbs., 21.5 miles at 200 lbs. |
Weight of Heaviest Piece7 |
125.7 lbs.(base) |
Warranty |
Frame: 5-year limited; Drivetrain: 13-month limited; Electronics: 13-month limited; Batteries: 13-month limited |
