The PASSPORT® Vertical Platform Lift provides safe home access for individuals with limited mobility. Used most commonly for difficult entrances such as tight pathways and high porches that may not offer enough space for a ramp, the PASSPORT is the perfect solution to eliminate barriers and will get you to...
PASSPORT with Straight Platform
PL44SP3651 |
PL52SP3651 |
PL72SP3651 |
|
|
|
|
---|---|---|---|---|---|---|
Lifting height (landing-to-landing) |
44″ |
52″ |
72″ |
|
|
|
Weight capacity |
750 lbs. |
750 Ibs. |
750 lbs. |
|
|
|
Unit weight |
339 lbs. |
367 lbs. |
398 lbs. |
|
|
|
Platform usable size (L x W) |
50.75″ x 36″ |
50.75″ x 36″ |
50.75″ x 36″ |
|
|
|
Warranty |
2-year |
2-year |
2-year |
|
|
|
PASSPORT with Turn Platform
PL44TP3860 |
PL52TP3860 |
PL72TP3860 |
|
|||
---|---|---|---|---|---|---|
Lifting height (landing-to-landing) |
44″ |
52″ |
72″ |
|
|
|
Weight capacity |
750 lbs. |
750 Ibs. |
750 lbs. |
|
|
|
Unit weight |
349 lbs. |
377 lbs. |
408 lbs. |
|
|
|
Platform usable size (L xW) |
59.75″ x 38″ |
59.75″ x 38″ |
59.75″ x 38″ |
|
|
|
Warranty |
2-year |
2-year |
2-year |
|
|
|
NOTE: Weights and dimensions are approximate and subject to change.
For additional specs and dimensions see “Documents”
